Description
Sikasil® IG-16 is a neutral-curing, high-modulus silicone insulating glass secondary sealant with excellent adhesion to many substrates.
Product Benefits
- Meets requirements of EN 1279,parts 2, 3 and 4
- Suitable for air- and gas-filled insulating glass units
- Excellent UV and weathering resistance
- Bonds well to glass as well as Metal and plastics spacers
- Fast curing
Areas of Application
Sikasil® IG-16 can be used as a UV resistant secondary edge seal for the manufacturing of dual-sealed insulating glass units. This product is suitable for professional experienced users only. Tests with original substrates and conditions have to be performed to ensure adhesion and material compatibility.
Technical data at 23ºC and 50% RV
| Chemical base |
1-C silicone |
| Color (CQP1001-1) |
Black |
| Cure mechanism |
Moisture-curing |
| Cure type |
Neutral |
| Density (uncured) (CQP 006-4) |
1.48 kg/l |
| Non-sag properties (CQP 061-4 / ISO 7390) |
< 2 mm |
| Application temperature |
5 °C – 40 °C |
| Skin time2 (CQP 019-2) |
Circa 25 minutes |
| Tack-free time2 (CQP 019-1) |
Circa 100 minutes |
| Curing speed (CQP 049-1) |
See diagram 1 |
| Shore A-hardness (CQP 023-1 / ISO 868) |
Circa 45 |
| Tensile strength (CQP 036-1 / ISO 37) |
Circa 1,8 N/mm² |
| Elongation at break (CQP 036-1 / ISO 37) |
Circa 300 % |
| Tear propagation resistance (CQP 045-1 / ISO 34) |
Circa 6,0 N/mm |
| 100% modulus (CQP 036-1 / ISO 37) |
Circa 1,2 N/mm² |
| Movement accommodation capability (ASTM C 719) |
± 12.5 % |
| Thermal resistance (CQP 513-1) |
Circa 180 °C
|
| Service temperature
4 hours
1 hour |
Circa 200 °C
Circa 220 °C |
| Moisture vapor transmission rate (CQP 520-2 / ISO 12572) |
Circa -40 °C tot + 150 °C |
| Shelf life (storage below 25 °C) (CQP 016-1) |
15 g H²O/m² ·24 h·circa 2 mm |
|
|
Application Limits
Most Sikasil® WS, FS, SG, IG, WT, AS and other engineering silicone sealants manufactured by Sika are compatible with each other and with SikaGlaze® IG sealants. For specific information regarding compatibility between various Sikasil® and SikaGlaze® products please contact the Technical Service Department of Sika Industry. All other sealants have to be approved by Sika before using them in combination with Sikasil® IG-16. Where two or more different reactive sealants are used, allow the first to cure completely before applying the next. Sikasil® SG, IG and WT sealants and adhesives may only be used in structural glazing or window bonding applications by experienced professionals and after a detailed examination and written approval of the corresponding project details by the Technical Department of Sika Industry. The compatibility of gaskets, backer rods, setting blocks and other accessory materials with Sikasil® IG-16 must be tested in advance.
